Honeywell MAXPRO Intrusion MPIP2000U/3000U Series Installation and Setup Guide
800-23044 Rev. A draft_11 73
# Item
Terminal or
connector
Connect to
E ENTRY
Reader
(Reader1)
+12V Entry reader power input [+].
– Entry reader input [–] for power and
tamper
D0 Entry reader data0
D1 Entry reader data1
T Entry reader tamper.
F Triggers LEDR Entry reader red LED. If used: exit reader
red LED.
LEDY Entry reader yellow LED. If used: exit
reader yellow LED.
LEDG Entry reader green LED. If used: exit
reader green LED.
BUZZ Entry reader buzzer. If used: exit reader
buzzer.
– Reader LEDs and buzzer [–] terminal.
G Door status
monitor
– Door status monitor [–] terminal.
DSM Door status monitor.
Default supervision: EOLR (2K). For details and more
options, see Wiring Inputs (Zones) on page39. Terminate
using resistors if not used.
Can be used as an entry/exit zone for burglary
protection.
H Door
Strike/Lock
(relay)
NC Normal Closed terminal
C Common terminal
NO Normal Open terminal
For door lock only: magnetic lock OR door strike.
I Transient protection for magnetic lock or door strike
J Auxiliary power supply for door strike/lock relay.
K Jumper Jumper for door strike/lock relay: 12VDC feed for the
relay NC/NO contact if jumper is positioned over pins1
and2. For details, see further below.
