NCA-2 Manual — P/N 52482:M5 03/20/2019 19
Section 3: Installation
3.1 Preparing for Installation
Choose a location for the NCA-2 that is clean, dry, and vibration-free with moderate temperature. The area should be readily accessible
with sufficient room to easily install and maintain it. There should be sufficient space for cabinet door(s) to open completely.
Carefully unpack the system and inspect for shipping damage. Count the number of conductors needed for all devices and find the appro-
priate knockouts. (Refer to Section 3.13 “UL Power-limited Wiring Requirements” for selection guidelines.)
Before installing the fire alarm system, read the following:
• Review the installation precautions at the front of this manual.
• Installers should be familiar with the standards and codes specified in Section 1.1 “Standards and Specifications”.
• All wiring must comply with the National and Local codes for fire alarm systems.
• Do not draw wiring into the bottom 9 inches (22.86 cm) of the cabinet except when using a separate battery cabinet; this space is for
internal battery installation.
• Review installation instructions in Section 3.2 “Installation Checklist”.
3.2 Installation Checklist
The checklist that follows contains references to information included in other manuals; see Section 1.4 “Related Documentation” for
document part numbers.
!
WARNING: RISK OF IRREPARABLE EQUIPMENT DAMAGE
MAKE SURE TO INSTALL SYSTEM COMPONENTS IN THE SEQUENCE LISTED BELOW. FAILURE TO DO SO CAN
DAMAGE THE CONTROL PANEL AND OTHER SYSTEM COMPONENTS.
!
WARNING: RISK OF IRREPARABLE EQUIPMENT DAMAGE
WEAR A STATIC DISCHARGE STRAP ON WRIST TO PREVENT EQUIPMENT DAMAGE.
Task Refer to:
1 Mount the cabinet backbox to the wall. Section 3.3 “CAB-4 Series Cabinet” and Section 3.4 “ABS-2D, ABS-4D
Cabinets”
For Canadian Applications, only the ABS-2DC and ABS-4DC backboxes and the CAB-4 Series Cabinets are approved for NCA-2
installation.
2 Attach NCA-2 to chassis Section 3.4 “ABS-2D, ABS-4D Cabinets”, Section 3.5 “CHS-M3 Chassis”,
and Section 3.6 “CA-2 Chassis Assembly”
3 Attach option boards (e.g. network
communications modules and other devices of the
same size) to chassis.
• Section 3.5.4 “Option Boards” and Section 3.4 “ABS-2D, ABS-4D
Cabinets”
• Installation document for the specific device
4 Complete backbox/chassis mounting. Section 3.4 “ABS-2D, ABS-4D Cabinets”, Section 3.5 “CHS-M3 Chassis”,
and Section 3.6 “CA-2 Chassis Assembly”
5 Wire Relays Section 3.9 “Form-C Relays” on page 26
6 Attach & wire other system components
Digital Voice components Digital Voice Control Manual, etc.
Annunciators and other ACS devices ACS Manual, etc.
Remote Data Port devices LCD-160 Manual, LCD-80 Manual (Terminal Mode)
Printer or other output device(s) Section 3.14 “Installing Printers”
Network devices Noti•Fire•Net Version 5.0 & Higher Manual, or High-Speed Noti•Fire•Net
Manual
and/or Installation document for specific device(s)
7 Calculate the proper battery rating. Main Power Supply Manual
8 Install main power supply & batteries. Run cable
to main & optional power supplies, DC power
outputs, relays, etc.
Section 3.12 “Connecting Power Sources and Outputs”
Section 3.13 “UL Power-limited Wiring Requirements”
Do not activate power at this time. Do NOT connect batteries.
Main power supply. Main Power Supply Manual
BB-100/200 Cabinet Installation Instructions
9 Check that all mounting holes are secured to insure a proper Earth Ground connection.
10 Connect wire shielding to Earth Ground.
11 Remove insulator from lithium battery on NCA-2. Section 3.5.3 “Memory-Backup Battery”
12 Apply AC power to the control panel by placing the external circuit breaker to the ON position.
Do NOT connect batteries until AC power is checked (see next step).
13 Check AC power. Section 3.12.3 “Checking AC Power”
14 Connect the batteries using interconnect cable as described in power supply manual.
15 Install the dress panels, doors and covers. CAB-3/CAB-4 Series Cabinet Installation Document
16 Program the NCA-2. Section 5, “Programming”, on page 54
17 Field test the system.
Table 3.1 Installation Checklist
!
