Operation The LCD Display
Local History
When you select this option, the Local History Select menu appears (see Figure 4.7 on page 42). The soft keys ALL EVENTS,
ALARMS ONLY, TROUBLES ONLY, SUPERVISORY ONLY, and SECURITY/OTHERS are used to select the type of history to be
viewed. Options will not appear if their associated history queue is empty. The TIME/DATE INTERVAL and POINT RANGE options
allow the user to select only events within those given parameters.
Figure 4.7 Local History Select Screen
For example, if a user selects TROUBLES ONLY, a screen similar to the full screen in at the top of Figure 4.8 may be displayed. All
Trouble events are shown in descending date order (from most recent to least recent). Event details are displayed in the middle area
marked off by separating lines. Details include the event type, node number, node location as defined by the operator, device type, and
the date and time of the event. The user can scroll through the Trouble event history by pressing the NEXT EVENT or PREVIOUS
EVENT soft keys. PRINT TROUBLE HISTORY will print the history of the selected event type. Pressing the BACK key will return to
the History Main menu.
HISTORY SELECT
ALL EVENTS SECURITY/OTHERS
ALARMS ONLY TIME/DATE INTERVAL
TROUBLES ONLY POINT RANGE
SUPERVISORY ONLY BACK
Main menu
History display
Local history
TROUBLE HISTORY
TROUBLE 0313 OF 0313
TROUBLE INVALID RESPONSE
DETECTOR 99
SMOKE(ION)
09:47:32A TUE JAN 22, 2019 N235L01D099
NEXT EVENT PRINT TROUBLE HISTORY
PREVIOUS EVENT BACK
Main menu
History display
Local history
Troubles only
ALARM HISTORY
ALARM 0168 OF 0168
CLEARED FIRE ALARM
MODULE L01M001
Zone 04 Z004 MONITOR
09:50:29A TUE JAN 22, 2019 N045L01M001
NEXT ALARM PRINT ALARM HISTORY
Alarms only
