68 Notifier SLC Wiring Manual — P/N 51253:U5 12/20/2017
Terminal Conversion Charts for V-type and H-type Devices FCM-1 and FZM-1
C.2 FCM-1 and FZM-1
C.3 FMM-1
C.4 FTM-1
V-type Terminal Number Terminal Function H-type Terminal Number
1SLC -1
2SLC +2
3 VDC - 11
4 VDC + 10
5Unused5
6 Solenoid B/A - 6
7 Solenoid B/A + 7
8 Solenoid A + 8
9 Solenoid A - 9
N/A Unused 3
N/A Unused 4
Table C.2 FCM-1 and FZM-1 Terminal Conversions
V-type Terminal Number Terminal Function H-type Terminal Number
1SLC -1
2SLC +2
3Unused3
4Unused4
5Unused5
6 Class A/B Supervision - 6
7 Class A/B Supervision + 7
8 Class A Supervision + 8
9 Class A Supervision - 9
N/A Unused 10
N/A Unused 11
Table C.3 FMM-1 Terminal Conversions
VDC -
VDC +
SLC -
SLC +
SLC -
SLC +
VDC -
VDC +
Class A Supervision A-
Class A SupervisionA+
Class A/B Supervision +
Class A/B Supervision -
Class A Supervision A-
Class A Supervision A+
Class A/B Supervision +
Class A/B Supervision -
Type V
Type H
SLC -
SLC +
Class A Supervision -
Class A Supervision+
Class A/B Supervision +
Class A/B Supervision -
Class A Supervision -
Class A Supervision+
Class A/B Supervision +
Class A/B Supervision -
SLC -
SLC +
Type V
Type H
