NCA-2 Manual — P/N 52482:M5 03/20/2019 51
The LCD Display Operation
LCD Display - Prints a report showing the brightness settings of the display, whether its backlight is on, and language of the display.
Figure 4.23 Printer Functions: LCD Display Report
ACS Programming - Print a list of all installed ACS devices and their types (64-point, 96-point, UDACT, TM4, etc.)
Figure 4.24 Printer Functions: ACS Installed Points Report
ACS Installed Points - Print a list of installed ACS devices, their types, and their programmed points.
Figure 4.25 Printer Functions: ACS Installed Points Report
Supervision - Print a report showing whether there is supervision for the power supply and tamper input, and what type of printer is
being used. When there is power supply supervision, the power supply node will be displayed.
Figure 4.26 Printer Functions: Supervision Report
Event Logging - Prints a report of the NCA-2 Event Logging settings for Non-Fire Activations and Output Activations.
Figure 4.27 Printer Functions: NCA-2 Output Activations Report
Active Points Reports
This printer functions option shows active points directly from the alarm queues. The SECURITY and OTHER queues are combined in
one printout. Only buttons which have active events are visible. Pressing one of these buttons will print the report and return the user to
the main menu. It is not possible to select all queues for printout at the same time.
Figure 4.28 Printer Functions: Active Points Report Menu
******LCD DISPLAY***************************************************************
LCD INTENSITY: 040 BACKLIGHT: ON
LANGUAGE: ENGLISH
********************************************************************************
******INSTALLED POINTS********************8*************************************
BOARD 01: 96 PT
MONITOR N102P01.1 N000A01P01
********************************************************************************
******ACS POINT PROGRAMMING*****************************************************
BOARD 03: 64 PT
POINT 01: ACKNOWLEDGE POINT 02: SILENCE N000
POINT 03: RESET N000 POINT 04: DRILL N000
********************************************************************************
******SUPERVISION***************************************************************
MAIN PS NODE:N000
PRINTER: 80-COLUMN
Tamper Input: NO
AUXILIARY TROUBLE:NO
********************************************************************************
******EVENT LOGGING************************************************************
NON-FIRE ACTIVATIONS:NOOUTPUT ACTIVATIONS: NO
********************************************************************************
NODE LABEL FOR LOCAL NCA
SYSTEM NORMAL
Node#
ACTIVE POINTS REPORT
ALARMS ONLY PREALARMS
TROUBLES ONLY DISABLED POINTS
SUPERVISORY ONLY ACTIVE OUTPUTS
SECURITY/OTHER BACK
Main menu
 Printer functions
 Active points
