NCA-2 Manual — P/N 52482:M5 03/20/2019 33
Connecting a PC for Programming Installation
PRN Printer Settings
Set the printer options (under the menu area) according to the settings listed in Table 3.3.
Keltron Printer VS4095/5 Settings
The printer communicates using the following protocol:
• Baud Rate
– Supervised mode: 2400
– Unsupervised mode: 300
(Supervision is a programmed setting; refer to the Panel
Programming section of the Programming Manual for
instructions.)
• Data bits: 8
• Parity: None
• Stop bits: 1
Set the printer DIP switches SP1 and SP2 according to settings in
Table 3.4.
3.15 Connecting a PC for Programming
A PC running the VeriFire
®
Tools programming utility can upload and download the operating program of the control panel when
attached to J1 Network/Service Connection (NUP) or to the second Network/Service connection on an attached network communica-
tions module. Refer to the VeriFire
®
Tools CD for instructions.
3.16 Annunciator Key Switch (AKS-1B)
Some jurisdictions allow one node on a network to control the network at a time; one way to meet this requirement uses AKS-1B or Con-
nector J6. For details, refer to Section 5.1 “Security Access” and your local Authority Having Jurisdiction.
The AKS-1B can provide access security for the control switches on the NCA-2. When key switch monitoring is enabled as described in
the Programming Section 5.5.7 “Supervision”, the NCA-2 keypad can only be used when the AKS-1B key is inserted and unlocked.
*Protocol: When printing in graphics mode, set I/O Serial
Protocol to “Robust XON/OFF”.
Option
Setting for Printer Model
PRN-6 and
previous models
PRN-7
L/R Adjust 0 0
Font HS Draft HS Draft
CPI 10 CPI 10 CPI
LPI 6 LPI 6 LPI
Skip 0.0 0.0
ESC Character ESC ESC
Emulate FX-850 LQ-2550
Bidirectional Copy ON ON
I/O
Interface
Buffer
Serial
Baud
Format
Protocol *
Serial
40K
9600, 4800, 2400
8 Bit, None, 1 Stop
ENQ/STX
Serial
64K
9600, 4800, 2400
8 Bit, None, 1 Stop
ENQ/STX
CG-TAB Graphic Graphic
Character Set Standard Standard
Country E-USA ASCII E-USA ASCII
Select Zero ON ON
Auto-CR OFF OFF
Auto-LF OFF OFF
Option
Setting for Printer Model
PRN-6 and
previous models
PRN-7
Menu Lock ON All
Language English English
Paper
Single
Form Adjust
Trac 1
Form Adjust
Trac 2
Form Adjust
Auto Sheet Feeder
Form Adjust
12/72
12/72
12/72
12/72
12/72
12/72
12/72
12/72
Auto Tear OFF OFF
F-Eject OFF Top
Form Length
Trac 1
Lines
Standard
Trac 2
Lines
Standard
66
10.5”
66
10.5”
66
11”
66
11”
Barcode Off Off
Barmode Unsecured Unsecured
Table 3.3 PRN Setup Options
Supervised Unsupervised
Supervised and
Unsupervised
SP1 On Off SP1 On Off SP2 On Off
1X1X1X
2X2X2X
3X3X3X
4X4X4X
5X 5X 5X
6X6X6X
7X 7X 7X
8X 8X 8X
Table 3.4 Keltron DIP Switch Settings
NOTE: Download operations that change the basic program of the control panel must be performed by responsible service personnel in
attendance at the control panel. After downloading a program, test the control panel in accordance with NFPA 72.
