46 NCA-2 Manual — P/N 52482:M5 03/20/2019
Operation The LCD Display
If a device does not exist at the selected address, an Invalid Point error message will display. Press “NEXT POINT” or “PREVIOUS
POINT” to read the next/previous programmed point of that type. If communicating with an NFS-320, NFS2-640, or NFS2-3030, the
NCA-2 will automatically proceed to the next point. In either case, an error message will indicate if there are no further devices of that type pro-
grammed.
Figure 4.12 Read Status Point Select Screen
Figure 4.13 Read Status Details - Smoke Detector Point Installed on an NFS-320 or NFS2-640
Figure 4.13 shows a sample status screen for a smoke detector point. Following is an explanation of the screen elements:
• Lines 1-4 can be any present event message or the System All Normal message.
• Line 5 is the screen header. It will display the current address of the point being read.
The area between the separator lines, lines 6-14, shows all information concerning the selected point, which is N003L01D051 in the
example above.
• Line 6 displays two statistics:
—Point Control:
Automatic - the point is being controlled automatically by the panel.
Manual - a status change has caused the point to go off of automatic control.
Forced - the point has been forced into another state by an outside source (such as another network node).
Disabled - the point is disabled.
—Point Status:
Active - the point is currently in an off-normal state.
Inactive - the point is currently reporting no events.
Pre-alarm - the point is in pre-alarm.
NODE LABEL FOR LOCAL NCA
SYSTEM NORMAL
Node#
POINT SELECT
POINT SELECT:
NxxxLyyDzzz (DETECTOR)
NEXT POINT ACCEPT
PREVIOUS POINT BACK
Display Area
Main menu
Read status
Point Field
Select the device
type by scrolling
through them with
the POINT SELECT
soft key. Then,
enter the device
address in this field
to display details for
that point and press
Accept.
ACKNOWLEDGED FIRE ALARM
DETECTOR ADDR L01D032
ZONE 003 Z003 SMOKE(PHOTO)
09:48:35A TUE JAN 22, 2019 N239L01D032
READ ADDRESS: N003L01D051
AUTOMATIC ACTIVE
DETECTOR ADDR 1D051
ZONE 03 Z003 SUP L(PHOTO)
Z003 ,
VALUE: 000% OF ALARM, 000% OF PREALARM
ALARM: 8= 2.12%, PREALARM: 8= 1.33%
ACTION/STATUS: NONE/VERY CLEAN
PEAK:142% VERIFY COUNT:03 CO-OP:CTR
09:56:27A TUE JAN 22, 2019
BACK
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
This shows
Point Control
This shows
Point Status
Main menu
Read status
Accept a point
To Next Page
