56 NCA-2 Manual — P/N 52482:M5 03/20/2019
Programming The Program/Alter Status Menu
5.2 The Program/Alter Status Menu
Press PROGRAM/ALTER STATUS on the Main Menu screen. The user must enter a password/user ID of up to eight digits to advance
to the Alter Status Menu or Program Menu.
If the password does not match a password in the database, an encrypted version of the master password will be shown.
Access to Program/Alter Status menu registers as a “Programming Mode” trouble and is tracked in event history.
Figure 5.3 Alter-Status Password Screen
After a valid password is entered, the NCA-2 will navigate to the PROGRAM/ALTER STATUS ENTRY screen. There are three possible
menus, which are detailed in the upcoming sections:
• ALTER STATUS MENU (Section 5.3 on page 57)
• NODE PROGRAM N
(Section 5.4 on page 64)
• PANELPROGRAM MENU (Section 5.5 on page 65)
• POINT PROGRAM MENU
The password access level determines which of these menus will be displayed. For example, a user who was not set up to have program-
ming rights, will only be allowed to access the Alter Status Menu. The master password always gives full access to all three options.
Figure 5.4 Program/Alter Status Entry Menu
NOTE: All events are annunciated during programming. If one of the annunciated events occurs, the NCA-2 will exit the Programming
screen and go to the Event Counts menu with the exception of troubles. Troubles will sound the piezo, but will not cause an exit to the
Events Counts Screen.
PROGRAM/ALTER STATUS ENTRY SCREEN
ENTER PASSWORD: ********
ACCEPT
BACK
Main menu
Program/alter status
PROGRAM/ALTER STATUS ENTRY MENU
ALTER STATUS MENU
NODE PROGRAM: N000
PANEL PROGRAM MENU ACCEPT
POINT PROGRAM MENU BACK
Main menu
Program/alter status
NOTE: Access to ACS board label screen is by selecting local NCA-2 node only.
