Programming Panel Program Menu
SAVE will save the current point programming without exiting the menu. Press NEXT to advance to the next ACS address for configur-
ing.
Figure 5.33 ACS Point Programming Screen
Figure 5.34 ACS Source Programming Screen
Shadow Supports direct shadowing of ACS points when the NCA-2 communicates with an
AM2020/AFP-1010 or AFP-300/400. Complete annunciator programming at the
FACP local to the point to be shadowed must be complete before NCA-2 shadow
programming is performed. The lights on the ACS points will shadow the lights on
the mapped ACS point, except any flashing sequence may be different.
The lights on the ACS points will
shadow the lights on the mapped ACS
point, except any flashing sequence
may be different.
Page Use this mode only when ACS point A32 is programmed as AMG. This function
allows the user to define a group of standard or high-speed NOTI•FIRE•NET™
control panels to function as one “system” for the purpose of Fire Fighter's
Telephone and ALL CALL paging. An ACS point in the range of A32P1 - A32P64
may be programmed as PAGE. The source for this point is a single node address. If
either an ALL CALL or Fire Fighter's Telephone's remote ALL CALL PAGE is active,
the NCA-2 will only command the programmed list of nodes to participate.
NOTE: If none of the points A32P01 - A32P64 are defined as the page function,
the NCA-2 will command the entire list of mapped nodes to participate.
The Point Active LED is lit if a
corresponding mapped node is active.
The Status (trouble) LED is on when a
point or zone is in trouble.
ACS Point
Mode
Function: Explanation
Table 5.4 ACS Point Mapping: Explanation of Point Modes (3 of 3)
ACS POINT PROGRAMMING
POINT: A01P01
MODE: CONTROL
SOURCE:
NEXT POINT SAVE
PREVIOUS POINT BACK
Main menu
 Program/alter status menu
 Panel program menu
 ACS programming
 Point programming
(Control selected)
Format of point
address and
number of
available sources
vary depending on
mode and node.
When MODE is
CONTROL, press
the SOURCE soft
key to enter or
view Source
information. See
Figure 5.34.
CONTROL POINT SELECT
POINT SELECT ACCEPT
Main menu
 Program/alter status menu
 Panel program menu
 ACS programming
 Point programming
(Control. Point Select)
Enter the control
source(s) in
these eight fields.
Control sources
may be SLC
modules, panel
circuit modules,
or Prioritized
Audio Matrix
points.
Press this soft key to toggle through the device point address formats.
