NCA-2 Manual — P/N 52482:M5 03/20/2019 73
Panel Program Menu Programming
While this screen is in effect, the intensity of the display will match the value shown on the line below the screen header. Press ACCEPT
to implement changes or BACK to exit without saving.
Figure 5.31 Program Menu: LCD Programming
5.5.6 ACS Programming
The ACS device is a remote, limited control device used by the NCA-2; the function of each ACS point is defined at the NCA-2. The
NCA-2 can be programmed to allow an ACS device to perform a variety of tasks, such as silencing a specific node, or a network-wide
function, such as silencing all panels on the network that are mapped to the NCA-2. You use an ACS device when you do not need the
depth of functionality of a NCA-2, or when you wish to perform NCA-2 functions remotely without having to go to the NCA-2’s physi-
cal location. ACS devices are connected to the NCA-2 via the EIA-485 ACS mode connector (TB3). Multiple ACS devices can be con-
nected by daisy-chaining to the previous ACS device.
You can move the cursor between fields with the up and down arrows. Press the ANNUNCIATOR TYPE soft key to scroll through the
following list of types. Stop at the appropriate type.
Type: Used for:
NONE (Nothing installed)
64 PT 64-point annunciation
64SYS 64-point annunciation, with first 8 points reserved
64SVC* 64-point service mode for Two Level Bypass
96DCC 96 point annunciation to be used with multiple Command Centers
96PT 96-point annunciation
96SYS 96-point annunciation, with first 8 points reserved
96SVC* 96-point service mode for Two Level Bypass
UDACT UDACT or UDACT-2
TM4 TM-4. (The TM-4 has the option to program the reverse polarity/relay outputs.)
AMG** AMG-1
FSCS Smoke control modules set for FSCS mode
HVAC Smoke control modules set for HVAC mode
UZC 64-point UZC programmed for monitor type only
Press ACCEPT to save any configuration changes or BACK to exit without saving. The POINT PROGRAMMING soft key navigates to
the point programming menu.
*Two Level Bypass: When an ACS board is programmed as a 64SVC or 96SVC type, the operator must enter the Program/Alter Status
mode of operation before pressing any push buttons to control points on these boards. If a push button is pressed while not
in the Pro-
gram/Alter Status screen, and no unacknowledged events exist, the password screen will automatically be displayed so the operator can
enter the Program/Alter Status mode.
**AMG Type Programming: An AMG (Audio Message Generator) at address 32 can be programmed by the NCA-2 for only the Page
function. AMGs at any other address cannot be programmed at the NCA-2.
LCD DISPLAY
LCD INTENSITY: 50%
BRIGHTER DEFAULT
DARKER CURRENT
LANGUAGE: ENGLISH ACCEPT
BACKLIGHT: ON EXCEPT AC FAIL BACK
Main menu
Program/alter status menu
Panel program menu
LCD display
NOTE: The local NCA-2 is not available as a target node for ACS point mapping; only remote devices can be targeted.
