Honeywell Notifier AFP-100

Notifier SLC Wiring Manual — P/N 51253:U5 12/20/2017 63
Installation SLC Surge Suppression
B.2.1 AFP-100 & AFP-200
DTK-2LVLP-F Connections
PLP-42N Connections
SLCP-30 Connections
B.2.2 AFP-300, AFP-400
NOTE: Use 12 AWG (3.31 mm
2
) to 18 AWG (0.82 mm
2
) wire with crimp-on connectors to connect the unit’s
ground terminal to equipment ground. Wire length must be minimized to provide best protection.
–
+
SLC Loop
SLC Terminal Block
S
L
C
-
l
v
l
p
1
.
w
m
f
Optional Four-wire Return Loop
Style 6 (Class A)
2LVLP-F
2LVLP-F
IN OUT
IN OUT
A-
B-
A+
B+
A Shield
B Shield
–
+
INPUT
OUTPUT
L1 L2 L3 L4
L1 L2 L3 L4
GRND
INPUT
OUTPUT
L1 L2 L3 L4
L1 L2 L3 L4
GRND
S
L
C
-
p
l
p
n
1
.
w
m
f
SLC Loop
SLC Terminal Block
Optional Four-wire Return Loop
Style 6 (Class A)
PLP-42N
PLP-42N
A-
B-
A+
B+
A Shield
B Shield
+
–
S
L
C
-
s
l
c
p
1
.
w
m
f
SLC Terminal Block
SLC Loop
Optional Four-wire Return Loop
Style 6 (Class A)
2LCP-30
IN OUT
A-
B-
A+
B+
A Shield
B Shield
IN OUT
2LCP-30
