Honeywell PC42d User Manual

Appendix B - Default Settings
User Instructions for PC42d Desktop Printer 45
Medium Settings
Setting
Description
Default Value
Medium type
Selects the type of medium to be loaded onto the printer.
Medium with
interval
Printing Method
Selects the printing method to be used by the printer.
Thermo-sensitive
Medium margin (X)
Sets the width of the margin from the left edge of the label near the
printer head to the edge of the printing area. The unit of
measurement is defined based on "Measurement Unit” specification.
0
Medium width
Set the width of the printing area from the margin (X) to that
measured by the printer head to the edge of the printing area. The
unit of measurement is defined based on "Measurement Unit”
specification.
812 points
Medium margin
(X)
Medium width

Honeywell PC42d Specifications

General

Color	No
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	104 mm
Display	-
Product color	Black
Ethernet LAN	Yes
USB 2.0 ports quantity	1
Flash memory	128 MB
Internal memory	64 MB
Built-in barcodes	1D, 2D, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR Code
Core diameter	38.1 mm
Maximum label width	110 mm
Maximum label length	0.99 m
Maximum roll diameter	128 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	15 - 80 %

Weight and Dimensions

Depth	174 mm
Width	184 mm
Height	222.5 mm
Weight	1500 g
