Honeywell SmartLine ST 800 User Manual

25 ST 800 Pressure Transmitter User’s Manual Revision 15
window.
2. Press the  or  buttons to scroll through the list of choices.
3. Press  to make your selection. The new selection will be stored in the transmitter and will be
displayed on the lower line, right justified.
4.2.5 The Advanced Display Menus
The advanced display menus are organized into three levels, as shown by Table 9. There is a <Return>
menu item at each level that allows the user to return to the previous level.
Table 9 – Advanced Display Main Menu Structure
Level 1
Level 2
Level 3
<Exit>
n/a
n/a
Diagnostics
Critical
Non-Critical
PILD (Optional)*
For details go to the Diagnostics Menu Table 10
Display Setup
LCD Contrast
Common Setup
Screen 1
Screen 2
… Screen
8
For details go to the Display Setup Menu Table 11
Note that the Advanced Display supports the
configuration of up to 8 different screens.
Calibration
Set Time Stamp
Zero Correct
LRV Correct
URV Correct Cal
Low Correct Cal
High Correct
Barometric Correct
SP Zero Correct
Reset SP Correct
Reset Corrects DAC
Trim
Loop Test
Factory Cal
For details go to the Calibration Menu Table 12
Transmtr Setup
Parameters
Enter LRV
Enter URV
Set LRV
Set URV
Install date
PILD (Optional)*
For details go to the transmitter Setup Menu
Table 13
Information
Display
Elec Module
Meter Body
For details go to the Information Menu Table 14
*This feature is available only if ST 800 Sensor supports PILD feature.
