87 ST 800 Pressure Transmitter User’s Manual Revision 15
PV Function Block Mode
The Function Block Mode is only displayed for Foundation Fieldbus transmitters.
The eight possible Modes are shown below.
OOS Out of Service
Auto Automatic
Man Manual
Cas Cascade
RCas Remote Cascade
Rout Remote Output IMan
Initialization Manual
LO Local Override
Process Variable Tag
User Configurable. This field has 14 characters
Engineering Units
User Configurable. This field has 8 characters
Pressure:
atm
bar
ftH2O @ 68F
gf/cm2
inH20 @ 39F
inH20 @ 60F
inH20 @ 68F inHg
@ 0C kgf/cm2
Pressure:
kPa
mbar
mmH2O @ 4C
mmH2O @ 68F
cmH2O @ 4C
mH2O @ 4C
mmHg @ 0C
MPa
Pa
psi
Torr
Temp:
o
C
o
F
o
R
K (Kelvin)
Other:
% (percent) mA
(milliamps)
Custom Text
Flow:
gal/min
gal/h
impgal/h
L/s
L/min
L/h
bbl/h
CFH
SCFM
SCFH
SCFD
MSCFH
MMSCFH
m3/h
lb/min
lb/h
kg/h
MT/h
Square Root Output
This indicator is displayed when the Transfer Function of the transmitter analog
output is set to “Square Root”.
Note that this indicator is not displayed on the Trend screens.
Bar Graph
The limits of the bar graph are user-configurable for each screen.
Trend Graph
The limits of the trend graph are user-configurable for each screen. The
amount of time visible on the Trend graph is also configurable.
4.5.4 Button operation during monitoring
When the operator screens are active on the advanced display, the increment and decrement buttons (
and ) can be used to move to the next or previous operator screen without waiting for the rotation time to
expire. Pressing the Enter button () will call up the main menu.
