76 ST 800 Pressure Transmitter User’s Manual Revision 15
4.2.7 The Basic Display Menu
The basic display Menu is implemented as one long single-level menu and will “wrap around” when it
reaches the start or end of the menu. Operation is as follows:
Press the  button to call up the Menu.
1. Select <Exit Menu> and press  to exit the Menu.
2. Use the  and  buttons to scroll through the list of menu items.
3. Press the  button to select an item for data entry or activation. When an item is selected for data
entry or activation, the cursor will jump to the lower line of the LCD to allow editing of the value.
No action is taken against a menu item until the user presses the  button.
4. If you want to abort a data entry operation, simply refrain from pushing any buttons for 10
seconds; the data entry operation will time out and the original value of the selected item will be
preserved.
Table 17 – The Basic Display Menus
LCD Contrast
»»»»»
Adjust the LCD contrast level.
Range from » (1) to »»»»»»»»» (9)
Default: »»»»»»» (7)
Press  to enter
menu selection
 and  to select
level.
 to enter
PV Display
Pressure
Pressure Units
Select Process
Variable (PV) to
be shown on the
display from list.
Press  to enter
menu selection
Percent Output
%
Custom Output
Loop Output
mA
PV Decimal
None
Select the PV decimal resolution to
be shown on selected screen from
list.
 and  to select
from list
 to enter
X.X
X.XX
X.XXX
Custom Units
Custom Units:
 and  to select
Alphanumeric
 to enter and
shift to next
character
(Available only
Enter custom text using any
when Custom

alphanumeric value up to 8
Output PV display
characters long.
is selected)
Scaling Low
(Available only
when Custom
#########
Press  to enter
Output PV display
Enter the low and high scaling
menu selection
is selected)
limits. These limits are used to
 and  to select
Scaling High
scale the loop output to the
number.
(Available only
desired value.
 to enter and
when Custom
Output PV display
#########
shift to next digit
is selected)
