75 ST 800 Pressure Transmitter User’s Manual Revision 15
Screen4 Pressure
Custom Unit
[68PCUNIT]

When “Custom” selected for
Screen4 Pressure Units, enter
the custom unit name.
Character string of pressure
custom unit text for display x
= any Alphanumeric value
Press  to
enter menu
selection
 to select
alphanumeric
character.
 to enter
and shift to
the next
character to
the right
Screen4 Pressure
Scaling Low
[69PSCLLO]
########
When “Custom” selected for
Screen4 Pressure Units, enter
the Screen4 Pressure Scaling
Low value.
Value of the pressure custom
engineering unit corresponding
to the LRV of the transmitter
The limits are:
-999999 to 999999
Press  to
enter menu
selection
 Menu to
select
number.
 to enter and
shift to the
next digit to
the right
Screen4 Pressure
Scaling High
[70PSCLHI]
########
When “Custom” selected for
Screen4 Pressure Units, enter
the Screen4 Pressure Scaling
High value.
Value of the pressure custom
engineering unit corresponding
to the URV of the transmitter
The limits are:
-999999 to 999999
Press  to
enter menu
selection
 Menu to
select
number.
 to enter and
shift to the
next digit to
the right
РасМню
[EXDMNU
]
Откл (DISABLE)
СтМеню (SD MENU)
Вкл (ENABLE)
->РсшМеню (EX MENU)
Select ‘Enable’ to enter ‘EX
MENU’ and ‘Disable‘to enter
into ‘SD MENU’
Press  to
enter menu
selection
Menu to
select from
list
 to enter
Выход
[EXIT
]
Exit
Exit from Menu
Exit from
Menu list
 to enter
