PREPARING FOR INSTALLATION
Contents of the box
Before you begin, unpack the shipment and check the parts list
against the components in the shipment.
Your shipment contains:
Multi device
One of the following Multi devices:
Code Item
VMC-00WENN1 Tema-Voyager Multi-0, it is used for management of only I/O,
no reader connection available..
VMC-01WENN1 Tema-Voyager Multi-1, it manages 1 reader and I/O
VMC-02WENN1 Tema-Voyager Multi-2, it manages up to 2 readers and I/O
VMC-03WENN1 Tema-Voyager Multi-3, it manages up to 3 readers and I/O
VMC-04WENN1 Tema-Voyager Multi-4, it manages up to 4 readers and I/O
Device support kit
Code Qty Item
P8160-5 4 Shunt Jumper, 2PINS, FEM, 2.54mm, 3.0A, -55C to
+105C
300-04883 12 Resistor: CARB. 392R 1/4W 1% THT LF (White)
300-04884 12 Resistor: METAL. 1K21, 1/4W 1% THT LF (Yellow)
300-07677 4 Resistor: CARB. 270R, 1%, 1/4W THT LF (Blue)
P460 12 Diodes 1N4004 or equivalent
700-04116 1 Lower seal rubber (to be used only when IP32 protection
is required)
700-04114 1 Upper seal rubber (to be used only when IP32 protection
is required)
800-19900 1 Tema-Voyager Multi - Quick Installation Guide
Optional Boards (included into a separate box)
Code Item
VMA-06 Tema-Voyager Multi Relay Output board: provides 4 Relay Output,
dry contact NO/NC 24V-3A.
Up to 3 can be added to a Multi device.
