63
CR68 RS485 2 TX/RX activity, Bi-color
LED, Red and Green
Red Blinking when TX is active
Green Blinking when RX is active
OFF=no RX/TX activity
CR69 RS485 3 TX/RX activity, Bi-color
LED, Red and Green
Red Blinking when TX is active
Green Blinking when RX is active
OFF=no RX/TX activity
CR70 RS485 4 TX/RX activity, Bi-color
LED, Red and Green
Red Blinking when TX is active
Green Blinking when RX is active
OFF=no RX/TX activity
CR78 Application status, Green ON=Application running
OFF= Application stopped
CR96 EBI communication, Red ON=Communication with EBI
stopped
OFF= Communication with EBI in
place
RJ45.1 Ethernet TX/RX activity
Green
Blinking when RX or TX is active
OFF= no RX/TX activity
RJ45.2 Ethernet physical link, 1G bit/s
Yellow
ON=Good link
OFF=no link or no 1G bit/s
LED1 Configurable I/O 1
Green LED
ON= Output
OFF= Input
LED2 Configurable I/O 2
Green LED
ON= Output
OFF= Input
LED3 Configurable I/O 3
Green LED
ON= Output
OFF= Input
LED4 Configurable I/O 4
Green LED
ON= Output
OFF= Input
LED5 Configurable I/O 5
Green LED
ON= Output
OFF= Input
LED6 Configurable I/O 6
Green LED
ON= Output
OFF= Input
LED7 Configurable I/O 7
Green LED
ON= Output
OFF= Input
LED8 Configurable I/O 8
Green LED
ON= Output
OFF= Input
LED9 DC or POE Power in LED,
Green,
ON=DC/POE present
OFF=DC/POE not present
Table 9 - Led
Device Tampers
Anti open tamper
An anti-open tamper S1 is present into the device. When the case is
closed the tamper switch is pressed and so switched off.
