13
VMA-07 Tema-Voyager Multi Emergency Relay Output board, provides:
4 Relay Output, dry contact NO/NC 24V-3A;
1 Input, dry contact, for emergency alarm, with separate power
supply.
Up to 1 can be added to a Multi device.
800-20479 Tema-Voyager Multi - VMA06, VMA07 - Quick Installation Guide
(only when optional boards are present)
Spare Parts
It is possible to order the following spare parts for this device:
Spare part
code
Code Item Q.ty
VMS-RUB 700-04114
700-04116
Upper Seal Rubber
Lowest Seal Rubber
5
VMS-KIT 100-05961 Resistors and diodes kit. 1
Mounting tools
The following screwdrivers are required for the installation:
• 3mm slotted screwdriver
• T10 Torx screwdriver
Calculation of the current provided by Multi
Multi device can be powered either with a 10V-30V DC
power supply, PoE or PoE+; each of these power sources can provide
a different amount of current used to power the Multi device itself,
outputs, readers and door locks directly supplied by the device.
Tema-Voyager Multi - Consumption Verifier spreadsheet is been
available into EBI Global Support repository to help in calculate the
max number of outputs, readers and door locks can be directly
connected to the device and to verify that their consumption is inside
what provided by the selected power supply source.
