USING RELAYS PLUGS-IN (VMA-06, VMA-07)
VMA-06 and VMA-07 are optional plugs-in used together with Multi
devices. When these are plugged on the Multi board and properly
configured using the related jumpers they turn the open collector
digital outputs of the board in relay outputs.
VMA-07 includes the connection for an input that drives the cut of the
power supply of the device in case of emergency.
Up to 3 relay output plugs-in can be connected to Multi.
These are the product codes and the characteristics of the plugs-in:
Code Item
VMA-06
Tema-Voyager™ Multi Relay Output board: provides 4
Relay Output, dry contact NO/NC 24V-3A.
VMA-07
Tema-Voyager™ Multi Emergency Relay Output board:
provides:
• 4 Relay Output, dry contact NO/NC 24V-3A;
• 1 Input, dry contact, for emergency alarm, with
separate power supply.
