Honeywell Tema-Voyager Multi VMC Series User Manual

62
See Appendix 1 for details.
SW1.5 Application Switches: Spare -
SW1.6 Application Switches: Manufacturing test.
DO NOT USE: This feature is used for factory test.
See Appendix 1 for details.
Open
SW3.1 RS485 (Reader 1) termination resistor, Data A.
ON = termination resistor inserted
OFF = termination resistor not inserted
Open
SW3.2 RS485 (Reader 1) termination resistor, Data B.
ON = termination resistor inserted
OFF = termination resistor not inserted
Open
SW4.1 RS485 (Reader 2) termination resistor, Data A.
ON = termination resistor inserted
OFF = termination resistor not inserted
Open
SW4.2 RS485 (Reader 2) termination resistor, Data B.
ON = termination resistor inserted
OFF = termination resistor not inserted
Open
SW5.1 RS485 (Reader 3) termination resistor, Data A.
ON = termination resistor inserted
OFF = termination resistor not inserted
Open
SW5.2 RS485 (Reader 3) termination resistor, Data B.
ON = termination resistor inserted
OFF = termination resistor not inserted
Open
SW6.1 RS485 (Reader 4) termination resistor, Data A.
ON = termination resistor inserted
OFF = termination resistor not inserted
Open
SW6.2 RS485 (Reader 4) termination resistor, Data B.
ON = termination resistor inserted
OFF = termination resistor not inserted
Open
SW7 System reset Open
Table 8 - Switches
LED
The below table lists the led and explain their meaning.
LED Function Values
CR18 Ethernet 10/100M bit/s Green ON= Ethernet working at
10/100M bit/s
OFF=Ethernet not working at
10/100M bit/s
CR25 Database status, Red ON=Database not present
OFF= Database present
