TECHNICAL SPECIFICATIONS
Parameter Value
Electrical
DC power supply 10-30VDC (for UL60950 compliance units must be supplied by a
separately certified NEC Class 2 (LPS) power unit)
POE power supply POE IEEE 802.3af-2003
Power consumption 4,8 W Board only
DC power supply: max 36 W
POE+: max 25.5W
POE: max 15.4W
Available current for
readers and locks
(supported only with
VMA-06, VMA-07 plug-in)
DC power supply: max 1500mA @ 12Vcc
POE+ : max 1500mA @ 12Vcc
POE : max 750mA @ 12Vcc
WARNING: check limits with Tema-Voyager Multi Consumption
Verifier tool
Inputs 4 fixed:
Supervised inputs with four statuses: Normal, Alarm, Cut, and Short
or two statuses: Open, Close.
Current: 0~10mA for each input
Voltage: +14V maximum; 0V minimum
Min detection time: 50ms
Outputs 4 fixed:
From the main Board: Power Open Drain (Mosfet) 12V-50mA
From the optional Relay Output board: dry contact NO/NC 24V-3A
Input/Output lines 8 configurable (same characteristics of the fixed input/output)
Technical
Microprocessor Freescale i.MX 6 SOLO 800 Mhz
Operative system LINUX
Flash Memory High reliability NOR Flash 128 Mbytes
SDRAM memory High performance DDR SDRAM 512 Mbytes
Real Time Clock Internal RTC; retention time 48 hours using super capacitor.
LAN Ethernet connection 10Mb/100Mb/1Gb BaseT standard unshielded cable on RJ45;
POE, POE+
RS485 connection 4 lines (OSDP protocol), alternative to the 4 Wiegand lines
4 monitored lines, alternative to the 4 RS485 lines
Physical
Size 240*140*60mm
Weight
(including carton box)
550g
Case PC+ABS UL V0 Thickness: 2.5mm
Not painted; Color: Grey RAL 7035
