20
CONNECTING THE CABLES
Caution:
To ensure IP32 protection to the device you must follow
what specified into “IP32 protection mount” chapter.
Cables to be connected are (see Figure 6 - Multi Wiring Diagram):
• DC power supply (only if the device is not supplied using
POE/POE+)
• Readers lines
• Ethernet (10/100/1G BaseT)
• Input/Outputs (both Fixed and Configurable)
Figure 6 - Multi Wiring Diagram
