Paging
Page Mode
When the scanner is out of the base, the paging button on the base pages the
scanner associated with that base. If you want to disable the paging button, scan
the Page Mode Off bar code, below. When Page Mode is off, the base will no longer
page the scanner when the button is pressed and no scanner is in the base. The red
LED on the base remains lit to indicate that Page Mode is off. (This light will go out
when the button is pressed, then back on when it’s released.) Default = Page Mode
On.
Page Pitch
When the scanner is out of the base and you press the Page button, the scanner
associated with that base begins beeping. You can set the pitch of the paging beep
for the scanner by scanning one of the following bar codes. Default = Low.
Scan in Cradle Off
* Scan in Cradle On
Shut Down Scanner in Cradle
* Page Mode On
Page Mode Off
* Low (1000 Hz)

Honeywell Xenon Series Specifications

General

IP Rating	IP42
Connectivity	USB, RS-232, Keyboard Wedge, IBM 46XX, Synapse, USB-CDC
Decode Capabilities	1D and 2D barcodes
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Light Levels	Ambient light up to 100, 000 lux
Field of View	Horizontal: 41.4°; Vertical: 32.2°
Interface	USB, RS-232, Keyboard Wedge, IBM 46XX
Humidity	5% to 95% (non-condensing)
Dimensions	104 mm x 71 mm x 160 mm (4.1 in x 2.8 in x 6.3 in)
Drop Resistance	Withstands 50 drops at 1.8 m (6 ft) to concrete
Drop Specification	Withstands 50 drops at 1.8 m (6 ft) to concrete
