Honeywell Xenon Series User Manual

306 Xenon/Granit User Guide
Xenon 1902/1902h/1912 Cordless Scanner Product
Specifications
Humidity 0 to 95% non-condensing
Mechanical Drop Operational after 50 drops from 6 feet
(1.83m) to concrete at 23°C
Vibration Withstands 5G peak from 22 to 300 Hz
ESD Tolerance Up to 15kV direct air
Up to 8 kV indirect coupling plane
Image Size 838 x 640 pixels
Scan Performance
Skew Angle +65°
Pitch Angle +45°
Motion Tolerance:
Streaming Presentation Trigger
up to 240 inches per second for 13 mil UPC
Symbol Contrast Grade 1.0 (20% or greater)
Parameter (Continued) Specification
Parameter Specification
Mechanical
Height 6.3 inches (160mm)
Length 4.1 inches (104.1mm)
Width 2.8 inches (71.1mm)
Weight 7.5 ounces (212.62g)
Electrical
Illumination LED:
Peak Wavelength 624nm +
18nm (red LED)
IEC 62471: “Exempt Risk Group”
442nm, 552nm (white LED)
IEC 62471: “Exempt Risk Group”
Aiming:
Peak Wavelength Laser 650nm
IEC 60825-1: “Class 2”
Peak Wavelength LED 624nm + 18nm (red LED)
520nm +
18nm (green LED)
IEC 62471: “Exempt Risk Group”
Optical Power Laser <1mW
Battery
Lithium Ion 2400 mAHr minimum
Number of Scans Up to 50,000 per charge

Honeywell Xenon Series Specifications

General

IP Rating	IP42
Connectivity	USB, RS-232, Keyboard Wedge, IBM 46XX, Synapse, USB-CDC
Decode Capabilities	1D and 2D barcodes
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Light Levels	Ambient light up to 100, 000 lux
Field of View	Horizontal: 41.4°; Vertical: 32.2°
Interface	USB, RS-232, Keyboard Wedge, IBM 46XX
Humidity	5% to 95% (non-condensing)
Dimensions	104 mm x 71 mm x 160 mm (4.1 in x 2.8 in x 6.3 in)
Drop Resistance	Withstands 50 drops at 1.8 m (6 ft) to concrete
Drop Specification	Withstands 50 drops at 1.8 m (6 ft) to concrete
