Honeywell Xenon Series User Manual

106 Xenon/Granit User Guide
Scanner Name
You may assign a name to each scanner you are using for identification purposes.
The default name is in the format “ScannerName_Model_SN_XXXXXXXXXX” Per-
form the rename operation using either the bar codes on page 107, or by sending
the serial command :ScannerName:BT_NAMNewName. where ScannerName is
the current name of the scanner, and NewName is the new name for the scanner.
To rename scanners with sequential, numeric names, scan the bar codes below.
Scan the Reset code after each name change and wait for the scanner to relink to
the base before scanning a bar code to rename the next scanner.
Batch Mode Transmit Delay Short
(250 ms)
Batch Mode Transmit Delay Medium
(500 ms)
Batch Mode Transmit Delay Long
(1000 ms)
0001
0002
0003
0004
0005

Honeywell Xenon Series Specifications

General

IP Rating	IP42
Connectivity	USB, RS-232, Keyboard Wedge, IBM 46XX, Synapse, USB-CDC
Decode Capabilities	1D and 2D barcodes
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Light Levels	Ambient light up to 100, 000 lux
Field of View	Horizontal: 41.4°; Vertical: 32.2°
Interface	USB, RS-232, Keyboard Wedge, IBM 46XX
Humidity	5% to 95% (non-condensing)
Dimensions	104 mm x 71 mm x 160 mm (4.1 in x 2.8 in x 6.3 in)
Drop Resistance	Withstands 50 drops at 1.8 m (6 ft) to concrete
Drop Specification	Withstands 50 drops at 1.8 m (6 ft) to concrete
