Honeywell Xenon Series User Manual

316 Xenon/Granit User Guide
CCB01-010BT-07N-BF Charge Base Product
Specifications
ESD Sensitivity Up to 15kV direct air
Up to 8 kV indirect coupling plane
Parameter (Continued) Specification
Parameter Specification
Mechanical
Height 3.2 inches (81.3mm)
Length 5.19 inches (131.8mm)
Width 3.98 inches (101.1mm)
Weight 6.3 oz (179g)
Electrical
Voltage: 4.5 to 5.5 volts
Current Draw:
Host Terminal Port 500mA
Aux Power Port 1A
Charge Time From shut down to fully charged:
3 minutes via standard USB only
1 minute via powered USB with external power
Radio
Frequency 2.4 to 2.5 GHz (ISM Band) Frequency Hopping
Bluetooth v.4.2
Range 33 ft. (10 m) typical
Data Rate Up to 130 kbps
Environmental
Temperature Ranges:
Operating 32 F to +122 F (0 C to +50 C)
Battery Charge 32 F to +122 F (0 C to +50 C)
Storage without battery -40 F to +158 F (-40 C to +70 C)
Humidity Up to 95% non-condensing
Mechanical Drop Operational after 50 drops from 3.28 feet
(1 m) to concrete
Vibration 5G Peak from 22Hz to 300Hz
ESD Sensitivity Up to 15kV direct air
Up to 8 kV indirect coupling plane

Honeywell Xenon Series Specifications

General

IP Rating	IP42
Connectivity	USB, RS-232, Keyboard Wedge, IBM 46XX, Synapse, USB-CDC
Decode Capabilities	1D and 2D barcodes
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Light Levels	Ambient light up to 100, 000 lux
Field of View	Horizontal: 41.4°; Vertical: 32.2°
Interface	USB, RS-232, Keyboard Wedge, IBM 46XX
Humidity	5% to 95% (non-condensing)
Dimensions	104 mm x 71 mm x 160 mm (4.1 in x 2.8 in x 6.3 in)
Drop Resistance	Withstands 50 drops at 1.8 m (6 ft) to concrete
Drop Specification	Withstands 50 drops at 1.8 m (6 ft) to concrete
