Honeywell Xenon Series User Manual

Xenon/Granit User Guide 153
LED Solid (No Flash)
Under normal operations, the scanner’s LED flashes once for a good read. You may
set the LED to remain on for a length of time after a good read instead of flashing.
Default = LED Solid Off (Resume Flash).
If you have scanned a bar code and don’t want to wait for the LED to turn off, press
the trigger a 2nd time and the LED turns off. You can then scan the next bar code.
Page Volume Control
Note: This setting is not supported by the Xenon 1900h scanner.
When you press the Page button on the base or Access Point, the scanners associ-
ated with that base or Access Point will begin beeping in response. If you pull the
trigger on a scanner that is beeping in response, or press the Page button on the
base or Access Point a second time, all associated scanners will stop beeping. The
following settings set the paging volume, independent of the volume used when
scanning bar codes. Default = Low.
* LED Solid Off
(Resume Flash)
LED Solid 1 Second
LED Solid 3 Seconds
LED Solid 5 Seconds
Page Volume Off
* Page Volume Low

Honeywell Xenon Series Specifications

General

IP Rating	IP42
Connectivity	USB, RS-232, Keyboard Wedge, IBM 46XX, Synapse, USB-CDC
Decode Capabilities	1D and 2D barcodes
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Light Levels	Ambient light up to 100, 000 lux
Field of View	Horizontal: 41.4°; Vertical: 32.2°
Interface	USB, RS-232, Keyboard Wedge, IBM 46XX
Humidity	5% to 95% (non-condensing)
Dimensions	104 mm x 71 mm x 160 mm (4.1 in x 2.8 in x 6.3 in)
Drop Resistance	Withstands 50 drops at 1.8 m (6 ft) to concrete
Drop Specification	Withstands 50 drops at 1.8 m (6 ft) to concrete
