Honeywell Xenon Series User Manual

Xenon/Granit User Guide 319
Xenon B&W Scanner Guaranteed Performance
Xenon Color Scanner (Model COL) Typical Performance
Focus High Density (HD) Standard Range (SR) Extended Range (ER)
Symbology
Near
Distance
Far
Distance
Near
Distance
Far
Distance
Near
Distance
Far
Distance
5 mil Code 39 in. .3 3.3 2.1 5.1 4.2 7.8
mm 7.62 83.8 53.3 129.5 106.7 198.1
13 mil UPC in. .7 6.1 .4 15.6 1.1 19.7
mm 17.8 154.9 10.2 396.2 27.9 500.4
20 mil Code 39 in. .7 7.8 .5 20.2 1.5 25
mm 17.8 198.1 12.7 513.1 38.1 635
6.7 mil PDF417 in. .5 3.8 .9 5.8 3.3 8.7
mm 12.7 96.5 22.9 147.3 83.8 221
10 mil Data Matrix in. .4 3.8 .9 6.6 3.4 10.3
mm 10.2 96.5 22.9 167.6 86.4 261.6
20 mil QR Code in. 1.2 6.4 .7 13 .9 18
mm 30.5 162.6 17.8 330.2 22.9 457.2
Resolution (1D Code 39) 3 mil (.076mm) 5 mil (.127mm) 5 mil (.127mm)
Resolution (2D Data Matrix) 5 mil (.127mm) 6.7 mil (.170mm) 7.5 mil (.191mm)
Focus High Density (HD) Standard Range (SR)
Symbology
Near
Distance
Far Distance Near Distance Far Distance
5 mil Code 39 in. 0 3.6 1.1 5.2
mm 0 91.4 27.9 132.1
13 mil UPC in. .4 5.9 .4 16.2
mm 10.2 149.9 10.2 411.5
20 mil Code 39 in. .4 8.4 .5 22
mm 10.2 213.4 12.7 558.8
6.7 mil PDF417 in. 0 3.8 .4 6
mm 0 96.5 10.2 152.4
10 mil Data Matrix in. 0 4.2 .5 7
mm 0 106.7 12.7 177.8
20 mil QR Code in. .4 6.8 .6 13.4
mm 10.2 172.7 15.2 340.4
Resolution (1D Code 39) 3 mil (.076mm) 5 mil (.127mm)
Resolution (2D Data Matrix) 5 mil (.127mm) 6.7 mil (.170mm)

Honeywell Xenon Series Specifications

General

IP Rating	IP42
Connectivity	USB, RS-232, Keyboard Wedge, IBM 46XX, Synapse, USB-CDC
Decode Capabilities	1D and 2D barcodes
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Light Levels	Ambient light up to 100, 000 lux
Field of View	Horizontal: 41.4°; Vertical: 32.2°
Interface	USB, RS-232, Keyboard Wedge, IBM 46XX
Humidity	5% to 95% (non-condensing)
Dimensions	104 mm x 71 mm x 160 mm (4.1 in x 2.8 in x 6.3 in)
Drop Resistance	Withstands 50 drops at 1.8 m (6 ft) to concrete
Drop Specification	Withstands 50 drops at 1.8 m (6 ft) to concrete
