312 Xenon/Granit User Guide
Granit 1981i Industrial Full Range Cordless Scanner
Product Specifications
Current Draw @5VDC ScanningStandby
470mA, 2.35W100mA, 0.5W
Power Supply Noise Rejection Maximum 100mV peak to peak, 10 to 100 kHz
Illumination LED:
Peak Wavelength 617nm + 18nm (amber LED)
IEC 62471: “Exempt Risk Group”
Aiming:
Peak Wavelength Laser 650nm
IEC 60825-1: “Class 2”
Optical Power Laser <1mW
Environmental
Temperature Ranges:
Operating -22F to +122F (-30C to 50C)
Storage -40F to +158F (-40C to 70C)
Humidity 0 to 95% non-condensing
Mechanical Drop Operational after 50 drops from 6.5 feet
(1.98m) to concrete at 23°, -30°, and 50°C
Vibration Complies with MIL-STD-810G, Method 514.6, Annex
C
ESD Tolerance Up to 20kV direct air
Up to 8 kV indirect coupling plane
Sealant Rating IP65
Image Size 1280 x 800 pixels
Scan Performance
Skew Angle +80° typical, 200 lux, EAN/UPC
Pitch Angle +70°typical, 200 lux, EAN/UPC
Motion Tolerance: 30 inches per second typical on 13 mil UPC/EAN bar
code 8 in. from scanner nose
Symbol Contrast 1D codes 30% or greater (typical, 200 lux, 13 mil)
2D codes 40% or greater (typical, 200 lux, 20 mil)
Parameter (Continued) Specification
Parameter Specification
Mechanical
Height 7.7 in. (195.6mm)
Length 5.2 in. (132.1mm)
Width 2.9 in. (73.7mm)
