Honeywell Xenon Series User Manual

Xenon/Granit User Guide 313
Weight 14.8 oz. (420g)
Electrical
Illumination LED:
Peak Wavelength 617nm + 18nm (amber LED)
IEC 62471: “Exempt Risk Group”
Aiming:
Peak Wavelength Laser 650nm
IEC 60825-1: “Class 2”
Optical Power Laser <1mW
Battery
Battery:
Lithium Ion 2400 mAHr minimum
Number of Scans at least 7200 scans (1 scan every 4 seconds for 8
hours)
Expected Hours of Operation 8
Expected Charge Time 4.5 hours
Radio
Frequency 2.4 to 2.5 GHz (ISM Band) Frequency Hopping
Bluetooth v.2.1
Range 330 ft. (100m) typical
Data Rate Up to 1 MBps
Environmental
Temperature Ranges:
Operating while not charging -4F to + 122F (-20C to 50C)
Operating while charging 41F to + 104F (5C to 40C)
Storage with battery* -4F to +95F (-20C to 35C) for storage up to 90
days
-4F to +68F (-20C to 20C) for storage up to 365
days
Storage without battery -40F to +158F (-40C to 70C)
Humidity Up to 95% non-condensing
Mechanical Drop Operational after 50 drops from 6.5 feet
(1.98m) to concrete at 23°, -30°, and 50°C
Vibration Complies with MIL-STD-810G, Method 514.6,
Annex C
ESD Sensitivity Up to 20kV direct air
Up to 8 kV indirect coupling plane
Sealant Rating IP65
Image Size 1280 x 800 pixels
Scan Performance
Skew Angle +80° typical, 200 lux, EAN/UPC
Parameter (Continued) Specification

Honeywell Xenon Series Specifications

General

IP Rating	IP42
Connectivity	USB, RS-232, Keyboard Wedge, IBM 46XX, Synapse, USB-CDC
Decode Capabilities	1D and 2D barcodes
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Light Levels	Ambient light up to 100, 000 lux
Field of View	Horizontal: 41.4°; Vertical: 32.2°
Interface	USB, RS-232, Keyboard Wedge, IBM 46XX
Humidity	5% to 95% (non-condensing)
Dimensions	104 mm x 71 mm x 160 mm (4.1 in x 2.8 in x 6.3 in)
Drop Resistance	Withstands 50 drops at 1.8 m (6 ft) to concrete
Drop Specification	Withstands 50 drops at 1.8 m (6 ft) to concrete
