Honeywell Xenon Series User Manual

196 Xenon/Granit User Guide
Check Digit
No Check Digit indicates that the scanner reads and transmits bar code data with
or without a check digit.
When Check Digit is set to Validate, but Don’t Transmit, the unit only reads NEC 2
of 5 bar codes printed with a check digit, but will not transmit the check digit with
the scanned data.
When Check Digit is set to Validate and Transmit, the scanner only reads NEC 2 of
5 bar codes printed with a check digit, and will transmit this digit at the end of the
scanned data. Default = No Check Digit.
NEC 2 of 5 Message Length
Scan the bar codes below to change the message length. Refer to Message Length
Description (page 188) for additional information. Minimum and Maximum
lengths = 2-80. Minimum Default = 4, Maximum Default = 80.
Off
* No Check Digit
Validate, but Don’t Transmit
Validate and Transmit
Minimum Message Length
Maximum Message Length

Honeywell Xenon Series Specifications

General

IP Rating	IP42
Connectivity	USB, RS-232, Keyboard Wedge, IBM 46XX, Synapse, USB-CDC
Decode Capabilities	1D and 2D barcodes
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Light Levels	Ambient light up to 100, 000 lux
Field of View	Horizontal: 41.4°; Vertical: 32.2°
Interface	USB, RS-232, Keyboard Wedge, IBM 46XX
Humidity	5% to 95% (non-condensing)
Dimensions	104 mm x 71 mm x 160 mm (4.1 in x 2.8 in x 6.3 in)
Drop Resistance	Withstands 50 drops at 1.8 m (6 ft) to concrete
Drop Specification	Withstands 50 drops at 1.8 m (6 ft) to concrete
