Honeywell Xenon Series User Manual

APPENDIX
A
Xenon/Granit User Guide 339
REFERENCE CHARTS
Symbology Charts
Note: “m” represents the AIM modifier character. Refer to International Technical
Specification, Symbology Identifiers, for AIM modifier character details.
Prefix/Suffix entries for specific symbologies override the universal (All Symbologies,
99) entry.
Refer to Data Edit beginning on page 161 and Data Format beginning on page 167
for information about using Code ID and AIM ID.
Linear Symbologies
AIM Honeywell
Symbology ID
Possible modifiers
(m)
ID Hex
All Symbologies 99
Codabar ]Fm 0-1 a 61
Code 11 ]H3 h 68
Code 128 ]Cm 0, 1, 2, 4 j 6A
Code 32 Pharmaceutical (PARAF) ]X0 < 3C
Code 39 (supports Full ASCII mode) ]Am 0, 1, 3, 4, 5, 7 b 62
TCIF Linked Code 39 (TLC39)
]L2 T 54
Code 93 and 93i ]Gm 0-9, A-Z,
a-m
i69
EAN ]Em 0, 1, 3, 4 d 64
EAN-13 (including Bookland EAN)
]E0 d 64
EAN-13 with Add-On
]E3 d 64
EAN-13 with Extended Coupon Code
]E3 d 64
EAN-8
]E4 D 44

Honeywell Xenon Series Specifications

General

IP Rating	IP42
Connectivity	USB, RS-232, Keyboard Wedge, IBM 46XX, Synapse, USB-CDC
Decode Capabilities	1D and 2D barcodes
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Light Levels	Ambient light up to 100, 000 lux
Field of View	Horizontal: 41.4°; Vertical: 32.2°
Interface	USB, RS-232, Keyboard Wedge, IBM 46XX
Humidity	5% to 95% (non-condensing)
Dimensions	104 mm x 71 mm x 160 mm (4.1 in x 2.8 in x 6.3 in)
Drop Resistance	Withstands 50 drops at 1.8 m (6 ft) to concrete
Drop Specification	Withstands 50 drops at 1.8 m (6 ft) to concrete
