CAN Communications
CAN Communications
Overview 100
CAN Port Wiring 101
Cscape Programming via CAN 101
Ladder-Controlled CAN Communication 101
Using CAN for I/O Expansion (Network I/O) 101
CAN and Termination and Bias 101
NOTE: For additional CAN information, refer to the CAN Networks manual (MAN0799) via Documentation Search
for more details .
Overview
The X4 OCs provides a CAN networking port, which is implemented with an 8-position RJ-45 modular jack. The con-
nector is labeled CAN and is red.
