HORNER HE-X4A - PWM Function Registers Map; HSC Functions Registers Map

System Register Tables
PWM Function Registers Map
Register PWM
%AQ3
--
%AQ4
%AQ5
--
%AQ6
%AQ7
PWM1 Duty Cycle (32-bit)
%AQ8
%AQ9
PWM1 Frequency (32-bit)
%AQ10
%AQ11
PWM2 Duty Cycle (32-bit)
%AQ12
%AQ13
PWM2 Frequency (32-bit)
%AQ14
HSC Functions Registers Map
Register Frequency Totalize Pulse Quad
%AI5-6 HSC1 (function) Accumulator Quad 1 Acc
%AI7-8 HSC2 (function) Accumulator
%AI9-10 HSC3 (function) Accumulator Quad 2 Acc
%AI11-12 HSC4 (function) Accumulator
%AQ1-2 HSC1 Preset
%AQ3-4 HSC2 Preset
%Q17 Clear HSC1 Clear Quad 1
%Q18 Clear HSC2 Set Quad 1
%Q19 Clear HSC3 Clear Quad 2
%Q20 Clear HSC4 Set Quad 2
Page 58 of 163
