HORNER HE-X4A - Visual Overview of X4

Intro to the X4
Intro to the X4
Visual Overview 11
Where to find more information for the X4 OCS 12
Connectivity to the X4 12
Features of X4 OCS 13
Visual Overview
Touch Screen - Press upper right corner to bring out the function keys and SYSTEM key
to access the Main Menu.
1. Touch Screen
2. High Capacity microSD Slot
3. RS232/RS485 Serial Connector
4. CAN Port (via RJ45)
5. LAN Port
6. USB Mini-B Port
7. Analog I/O
8. DC Inputs
9. DC Outputs
10. DC Power
Page 11 of 163
