Ethernet Communications
Ethernet Communications
Ethernet Module Protocols and Features 103
Ethernet System Requirements 103
Ethernet Module Specifications 103
Ethernet Module Configuration 104
Ethernet Configuration – IP Parameters 107
Ethernet Module Protocol Configuration 107
NOTE:Refer to the Ethernet Supplement (SUP0740)on the Document Search page for more details.
Ethernet Module Protocols and Features
The following table describes the Ethernet Module Protocols and features supported by the Ethernet port on a Micro
OCS controller.
Protocol / Feature Protocol / Feature Description
ICMP (Ping) Internet Control Message Protocol
EGD Ethernet Global Data
Modbus Slave Modbus over Ethernet
Ethernet / IP ODVA CIP over Ethernet
FTP (File Server) File Transfer Protocol
ASCII over TCP/IP ASCII Data over Ethernet
Ethernet System Requirements
Full Ethernet functionality requires:
n
PC running Cscape Programming Software Version 9.8 or later (for configuration).
n
Micro OCS controller with onboard Ethernet port.
Ethernet Module Specifications
Speeds 10 BaseT Ethernet (10Mbps) 100 BaseTx Fast Ethernet (100Mbps)
Modes Half or Full Duplex
Auto-Negotiation Both 10/100Mbps and Half/Full Duplex
Connector Type Shielded RJ-45
Cable Type
(Recommended)
CAT5 (or better) UTP
Port Auto MDI/MDI-X (Auto Crossover)
Page 103 of 163
