System Register Tables
%SR Registers
Soft Key 4 = 37
Soft Key 5 = 38
Soft Key 6 = 39
Soft Key 7 = 40
Soft Key 8 = 41
Release = 255 (Keys pressed since
power-
up but not currently)
%SR57 LCD Backlight Dimmer Register
0-100 = 0% to 100% On
100-255 = 100% On
0 to 255 Read Only Read Only
%SR57.16 Temporarily disable Screen Saver Read/Write Read/Write
%SR58 User LEDs USER_LEDS Read/Write Read/Write
%SR59
Engine Build Number
(Only last three numbers displayed)
Read Only Read Only
%SR60 Build Option
Build Test = 0
Build Beta = 1
Build Product = 2
0 to 2 Read Only Read Only
%SR61 Number of CsCAN Network IDs NUM_IDS Read Only Read Only
%SR62-100 Reserved
%SR101.3 WebMI License Details – WebMI server
status
XLEe & XLTe only
Read Only Read Only
%SR101.4 WebMI License Details – WebMI user
logged in status
X2, X4, X7 & X10
Read Only Read Only
%SR101.8 - 101.16 WebMI License Details – Number of
users
X2, X4, X7 & X10
Read Only Read Only
%SR102 - 107 Reserved
%SR108
WebMI License Details – Number of
webpages
X2, X4, X7 & X10
Read Only Read Only
%SR109 WebMI License Details – Number of
datapoints
X2, X4, X7 & X10
Read Only Read Only
%SR110-112 WebMI License Details – Expiry date of
WebMI license
XLEe & XLTe only
Read Only Read Only
%SR113-130 Reserved
%SR131-135 OCS Model: ASCII, 10 characters Read Only Read Only
%SR136 Communication Download Timeout Read Only Read Only
%SR137 Communication Idle Timeout Read Only Read Only
%SR138-148 Reserved
%SR149-150 Free-running 10kHz count: 1 count =
0.1ms
(32-Bit DINT)
Read Only Read Only
%SR151 Reserved
%SR152 RS-485 Termination Read/Write Read/Write
%SR152.1 MJ2 Termination Enable Read/Write Read/Write
Page 53 of 163
