High Speed I/O
PWM Examples
Example 1 Duty Cycle Frequency
To get a 50% Duty Cycle @ 10kHz waveform on PWM1: Set %AQ7 – 8 = 16,000 Set %AQ9 – 10 = 10,000
Example 2 Duty Cycle Frequency
To get a 25% Duty Cycle @ 5kHz waveform on PWM2: Set %AQ11 – 12 = 8,000 Set %AQ13 – 14 = 5,000
Example 3 Duty Cycle Frequency
To turn PWM 1 output ON all the time: Set %AQ7 – 8 = 32,000 Set %AQ9 – 10 = Any Value
Example 4 Duty Cycle Frequency
To turn PWM 1 output OFF all the time: Set %AQ7 – 8 = 0 Set %AQ9 – 10 = Any Value
Page 93 of 163
