HP 5920 Series Fundamentals Configuration Guide

66
[Switch] vlan 10
[Switch-vlan10] quit
[Switch] vlan 30
Permission denied.
# Verify that you cannot configure any interface except Ten-GigabitEthernet 1/0/1 to
Ten-GigabitEthernet 1/0/20. Take Ten-GigabitEthernet 1/0/2 and Ten-GigabitEthernet 1/0/22 as
examples.
[Switch] vlan 10
[Switch-vlan10] port ten-gigabitethernet 1/0/2
[Switch-vlan10] port ten-gigabitethernet 1/0/22
Permission denied.
RBAC configuration example for HWTACACS authentication
users
Network requirements
As shown in Figure 22, the switch uses local authentication for login users, including the Telnet user. The
Telnet user uses the username test@bbb and is assigned the user role level-0.
Configure the remote-then-local authentication mode for temporary user role authorization. The switch
uses the HWTACACS server to provide authentication for obtaining the level-3 user role. If the AAA
configuration is invalid or the HWTACACS server does not respond, the switch performs local
authentication.
Figure 22 Network diagram
Configuration procedure
1. Configure the switch:
# Assign an IP address to VLAN-interface 2 (the interface connected to the Telnet user).
<Switch> system-view
[Switch] interface vlan-interface 2
[Switch-Vlan-interface2] ip address 192.168.1.70 255.255.255.0
[Switch-Vlan-interface2] quit
# Assign an IP address to VLAN-interface 3 (the interface connected to the HWTACACS server).
[Switch] interface vlan-interface 3
[Switch-Vlan-interface3] ip address 10.1.1.2 255.255.255.0
[Switch-Vlan-interface3] quit
