4 Maintaining the MSD
To remove the diffusion pump
115
10 Remove the diffusion pump through the side of the MSD.
You may have to tilt the pump slightly to remove it. Do not tilt the pump past 45° if
the pump is warm.
KF50 clamp
O-ring assembly
Diffusion pump
Diffusion pump outlet
Foreline gauge assembly
