146
4 Maintaining the MSD
To remove the ion source
To remove the ion source
Materials needed: Gloves, clean, lint-free
large (8650-0030)
small (8650-0029)
Pliers, long-nose (8710-1094)
1 Vent the MSD (page 52).
2 Open the vacuum manifold (page 54).
Make sure you use an anti-static wrist strap and take other anti-static precautions
before touching analyzer components.
3 Disconnect the 7 colored wires from the ion source.
4 Disconnect the wires for the ion source heater and temperature sensor
from the feedthrough board.
5 Remove the thumbscrews that hold the ion source in place.
6 Pull the ion source out of the source radiator.
&$87,21
Pull on the connectors, not on the wires.
: $ 5 1 , 1 * 7KHDQDO\]HURSHUDWHVDWKLJKWHPSHUDWXUHV'RQRWWRXFKDQ\SDUWXQWLO\RXDU HVXUHLWLV
FRRO
