HP 5973 - To Remove a Filament

158
4 Maintaining the MSD
To remove a filament
To remove a filament
Materials needed: Gloves, clean, lint-free
large (8650-0030)
small (8650-0029)
Hex ball driver, 1.5-mm (8710-1570)
1 Vent the MSD (page 52).
2 Open the vacuum manifold (page 54).
3 Remove the ion source (page 146).
4 Remove the filament(s) to be replaced.
: $ 5 1 , 1 * 7KHDQ DO\] HURSHUDWHVDWKLJKWHPSHUDWXUHV'RQRWWRXFK DQ\SDUWXQWLO\RXDUHVXUHLWLV
FRRO
