HP 5973 - To Replace the Fan for the High Vacuum Pump

134
4 Maintaining the MSD
To replace the fan for the high vacuum pump
To replace the fan for the high vacuum pump
Materials needed: Fan (3160-1037)
Screwdriver, TORX T-15 (8710-1622)
1 Vent the MSD (page 52).
2 Remove the upper and lower MSD covers (page 50).
3 Disconnect the fan wiring from the connector on the MSD frame.
4 Remove the 4 fan screws and remove the fan.
Keep the 4 screws.
5 Disconnect the fan wiring and safety grill from the old fan.
The fan wiring ends in a small connector on the back of the fan
6 Connect the fan wiring and safety grill to the new fan.
7 Install the new fan and reinstall the 4 screws.
8 Connect the fan wiring to the fan connector on the MSD frame.
9 Reinstall the MSD covers.
10 Pump down the MSD (page 58).
: $ 5 1 , 1 * 'RQRWWRXFKWKHKLJKYDFXXPSXPS7KHKLJKYDFXXPSXPSVHVSHFLDOO\WKHGLIIXVLRQSXPS
RSHUDWHDWGDQJHURXVO\KLJKWHPSHUDWXUHVDQGFRXOGVWLOOEHKRWHQRXJKWREXUQ\RX
: $ 5 1 , 1 * 0DNHVXUHWKHVDIHW\JULOOWKDWVKLHOGVWKHIDQEODGHVLVLQSODFH
