2 Operating the MSD
To set monitors for MSD temperature and vacuum status
To set monitors for MSD temperature and vacuum status
Monitors display the current value of a single instrument parameter. They can be
added to the standard instrument control window. Monitors can be set to change
color if the actual parameter value varies beyond a user-determined limit from the
parameter setpoint. This procedure describes how to add monitors to your instru-
ment control view.
Software changes The software is revised periodically. If the steps in this procedure do not match
your MSD ChemStation software, refer to the manuals and online help supplied
with the software for more information.
1 Select
MS Monitors from the Instrument menu.
2 In the Edit MS Monitors box, under Type, select
Zone.
3 Under Parameter, select
MS Source and click Add.
4 Under Parameter, select
MS Quad and click Add.
5 Under Parameter, select
Foreline (or TurboSpd) and click Add.
6 Click
OK.
The new monitors will be stacked on top of each other in the lower right corner of
the Instrument Control window. They must be moved for you to see them all.
7 Click and drag each monitor to the desired position.
See the accompanying illustration for an example of arranging the monitors.
8 To make the new settings part of the method, select
Save from the Method
menu.
