4 Maintaining the MSD
To disassemble the ion source
149
Entrance lens
Lens insulator (one of a pair)
Drawout plate
Drawout cylinder
Ion focus lens
Filament
Repeller nut (do not overtighten)
Washer
Repeller insulator
Source heater assembly
Interface socket
Source body
Set screw
Repeller
Repeller insulator
Filament
