180
4 Maintaining the MSD
To adjust the RF coils
8 Repeat steps 4 through 7 for 650 amu.
The minimum voltage is typically between 500 and 650 mV.
9 Exit the Set RFPA program.
10 Select
MS OFF from the Diagnostics menu.
11 Reinstall the upper MSD cover.
12 Tune the MSD (page 48).
RF coil adjustment screw
RF coil adjustment screw
