2 Operating the MSD
To open the vacuum manifold
55
4 Gently open the side plate.
Rear thumbscrew –
do not tighten
Source power cable
Side board control cable
Front thumbscrew
Side plate
&$87,21
If you feel resistance, stop. Do not try to force the side plate open. Applying force will ruin
the side plate. Verify that MSD is vented. Verify that both the front and rear side plate
screws are completely loose.
