HP AdvanceStack 10Base-T Hub-12 User Manual

3. Place the hub in the rack and lower it so the notches in the bottom
of the bracket slide onto the two screws. Tighten these screws—be
careful not to overtighten.
4. Install the other two number 12-24 screws into the upper hole in
each bracket. Be careful not to overtighten these screws.
Continued on the next page.
Upper hole in the
bracket
Lower notch in the
bracket
Install additional
screw
Installing the
HP AdvanceStack Hubs
Installing the HP AdvanceStack 10Base-T Hubs
1-8
