HP AdvanceStack 10Base-T Hubs
At A Glance
The HP AdvanceStack 10Base-T hubs are a family of multiport repeaters.
With these hubs, you can connect computers and other devices together in
an unshielded twisted-pair cable network. These hubs are compliant with
the IEEE 802.3 Type 10Base-T standard and support both 802.3 and Ethernet
networks. There are three models in the HP AdvanceStack 10Base-T hub
family:
Thin LAN
Extension
Distributed Management
RS-232
In Out
85
Reset Exp Slot Security Activity
ThinLAN Console AUI/Xcvr Collision
10Base-T
Hub-12
6
7
129 310 41112
Power
Fault
AdvanceStack HP J2600A
AUI/Xcvr
Slot
HP AdvanceStack 10Base-T Hub-12 (HP J2600A)
HP AdvanceStack 10Base-T Hub-24 (HP J2601B)
HP AdvanceStack 10Base-T Hub-48 (HP J2602B)
iii
